Chassis

Its mechanically welded chassis made from high elasticity steel gives it lightness and reliability in any test. Thanks to its compact road size, it can travel everywhere at high speed and during intensive work in the fields. "A" frame hitch is standard and makes tractor hitching simple and fast.

Tanks

Rotomolded in high density polyethylene, our tanks are light and chemical and schock resistant. Their smooth internal walls limit chemical residues and facilitate cleaning.

Main tank: 1200 or 1600L (less than 3,5L in the deep sump). Equipped with 3 Lav’Ton (rotating tank washing nozzles) to facilitate tank cleaning, the MAXIS is your ideal companion.

Rinsing tank: with a capacity of 180L to ensure a thourough cleaning of the boom lines and spraying circuit as well as the main tank.

Booms/Nozzle holders

TecLine-R: 21 - 24 - 27 - 28 or 30m rear vertical folding / 6 - 7 - 8 sections.

PENTIX: Multiple nozzle holders with diaphragm check valve

PENTIX SP: Multiple nozzle holders with diaphragm check valve and automatic rotation/selection

TECNOMA's Benefits

  • Rugged chassis.
  • More comfort with the TECFLOW electric anti-overflow system.
  • More comfort with NOVAFLOW: automatic filling system and anti-overflow function.
  • Hose reel + hand lance supplied with clear water to rinse all your equipment at the end of the work.
  • 2 LED bluebeams working lights to illuminate the booms (optional).
